Showing 0–10 of 14 results

- Use with SIP (Session Initiation Protocol) VoIP PBXU- Use with Valcom multi-zone page control unit with Centrex or C.O. lines (DTMF signaling only)- Use with Valcom handsfree page units for talkback paging- Multiple units may be connected for multi-zone paging with all call behind a PABX- Background music, stereo or mono input; music mutes during page- Volume controls for background music and tones- Security code option to restrict page access- Store & Play feedback eliminator option- Multiple disconnect options- Page verification tone- Customizable Page alert tone- Drive up to 150 one-way amplified speakers on 8 Ohm output (one-way output)- Web interface for programming extended functions

Valcom 6 Channel Amplifier 6 Independent channels of amplification 4 10W Outputs 2 40W Outputs Quick release screw terminals Activity LED indicators High pass horn filter on 40W Outputs Independent volume controls for each channel Power indicator Transformer coupled inputs

- 1 Zone one-way analog page control- Background music input with voice operated mute- Page override for special priority announcements- Battery back-up input - Built-in power - UL listed- Access: page port, PBX loop-start trunk port, electronic or 1A2 line key (line card required), or dedicated singleline phone set- Input impedance: 600 ohm- Music source impedance: 4 to 600 ohm- Music input level: -10dBm nominal- DC output: -24 Vdc @ 600 mA- Power requirements: 120 Vac/1A- VALCOM POWER UNITS (+12)

- 3 Zone one-way page control- Provides tandem all call- Background music input, automatically mutes in zonebeing paged- Page override for special priority announcements- Features are programmable per zone- Built-in tone generator for night ringing, time clock tone, doorbell- Accepts pulse and tone dial- Battery back-up input - UL listed- To interface with analog extension or Centrexline add the VC-V-9970- Access: page port on selected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phoneset- Input impedance: 600 ohm- Music sourceimpedance: 4 to 600 ohm- Music input level: -10dBm nominal- DC output: -24 Vdc @ 500 mA- Power requirements: 230 Vac/.5A or 120 Vac/1A- Weight: 6.25lbs- Dimensions: 7.1"H x 10"W x 3"D- VALCOM POWER UNITS (+20)

- 3 Zone talkback analog page control- Provides tandem all call- Background music input, automatically mutes inzone being paged- Page override for special priority announcements- Features are programmableper zone- Built-in tone generator for night ringing, time clock tone, doorbell- Accepts pulseand tone dial- Supports up to 2 talkback speakers and 40 one-way speakers per zone- Battery backup input- UL listed- Access: page port onselected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key (line card required), or dedicated single line phone set- Input impedance: 600 ohm- Music source impedance: 4 to 600 ohm- Music input level: -10dBm nominal- DC output: -24 Vdc @ 500 mA-Power requirements: 230 Vac/.5A or 120 Vac/1A-Weight: 6.25lbs- Dimensions: 7.1"H x 10"W x 3"D- VALCOM POWER UNITS (+10)

- 6 Zone one-way analog page control- All call- Background music input, automatically mutes in zone being paged-Page override for special priority announcements- Features are programmable per zone- Built-in tone generator for night ringing, time clock tone, doorbell- Accepts pulse and tone dial- Battery back-up input - Built-in power- UL listed- To interface with analog extension or Centrex line add the VC-V-9970- Access: page port on selected telephone systems, PBX loop start or ground-start trunk port, electronic or 1A2 line key(line card required), or dedicated single line phone set- Input impedance: 600 ohm- Music source impedance: 4 to 600 ohm- Music input level:-10dBm nominal- DC output: -24 Vdc @ 1.5A- Power requirements: 230 Vac/1A or 120 Vac/2A- Weight: 10lbs- Dimensions: 10.9"H x 13"W x 2.7"D- VALCOM POWER UNITS (+30)

24 POINT ONE WAY PAGINGEXPANSION CARDFOR VALCOM MULTIPATH

- Designed to convert the hands-free talkback audio outputs of V-TCM station cards to the appropriate level and impedance necessary for the input of one-way amplifiers and/or Valcom One-Way Self Amplified Speakers or Horns- Input 1000 Ohms- Output less than 20 Ohms

Valcom VBS11 Surface Mount for use with VIP-418, VIP-428, VIP-418-IC, VIP-428-IC

- The Valcom VB-A13 is a backbox for angled mounts VIP-418, VIP-428, VIP-418-IC, VIP-428-IC
