<p>EX9200 Switch Fabric</p> The EX9200-SF3 and EX9200-SF2 Switch Fabric modules are hot- swappable and serves as the central non-blocking matrix through which all network data passes. The EX9200-SF2 supports 480 Gbps throughput per slot and the EX9200-SF3 supports 1.5 Tbps throughput per slot. <br /><br />On the EX9204 and EX9208 switches, two EX9200-SF3 or EX9200-SF2 Switch Fabric modules deployed in a redundant configuration deliver up to 1.5 Tbps or 480 Gbps system throughput per slot, respectively. The Switch Fabric module installed first functions as the master, while the second serves as a backup.<br /><br /> On the EX9214, three EX9200-SF3 or EX9200-SF2 Switch Fabric modules deployed in a redundant configuration deliver 1.5 Tbps or 480 Gbps system throughput per slot, respectively. Traffic is load- balanced across the first two Switch Fabric modules installed, which together function as the master switch fabric, while the third serves as a backup.<br /> <p>Switch Fabric modules perform the following key functions:</p> <ul> <li>Monitoring and controlling systemfunctions</li> <li>Interconnecting all line cards</li> <li>Clocking and system resets</li> <li>Acting as Routing Engine carrier</li> </ul>
Manufacturer
Juniper Networks, Inc
Product Name
Switch Fabric Module
Brand Name
Juniper
